Description
Victron MultiPlus 12/1200-50-16
O Victron MultiPlus 12/1200-50-16 νέου τύπου σκοπό έχει να αντικαταστήσει την προηγούμενη σειρά MultiPlus Compact. Είναι ένας ισχυρός αντιστροφέας πραγματικά ημιτονοειδούς κύματος, ένας εξεζητημένος φορτιστής μπαταριών με τεχνολογία προσαρμοζόμενης φόρτισης και ένας υψηλής ταχύτητας διακόπτης μεταφοράς εναλλασσομένου ρεύματος, όλα σε ένα ενιαίο συμπαγών διαστάσεων περίβλημα.
8. TECHNICAL DATA
| 12 Volt |
MultiPlus 12/500/20 |
MultiPlus 12/800/35 |
MultiPlus 12/1200/50 |
|||||||||
| 24 Volt |
MultiPlus 24/500/10 |
MultiPlus 24/800/16 |
MultiPlus 24/1200/25 |
|||||||||
| 48 Volt |
MultiPlus 48/500/6 |
MultiPlus 48/800/9 |
MultiPlus 48/1200/13 |
|||||||||
| PowerControl / PowerAssist |
Yes / No |
Yes / Yes | ||||||||||
| Transfer switch |
16A |
|||||||||||
|
INVERTER |
||||||||||||
| Input voltage range |
9,5 – 17V |
19 – 33V |
38– 66V | |||||||||
| Output |
Output voltage: 230VAC ± 2% |
Frequency: 50Hz ± 0,1% (1) | ||||||||||
| Cont. output power at 25°C |
(3) |
500VA |
800VA |
1200VA |
||||||||
| Cont. output power at 25°C |
430W |
700W |
1000W |
|||||||||
| Cont. output power at 40°C |
400W |
650W |
900W |
|||||||||
| Cont. output power at 65°C |
300W |
400W |
600W |
|||||||||
| Peak power |
900W |
1600W |
2400W |
|||||||||
| Maximum efficiency |
90 / 91 / 92% |
92 / 93 / 94% |
93 / 94/95% |
|||||||||
| Zero-load power |
6 / 6 / 7W |
7 / 7 / 8W |
10 / 9 / 10W |
|||||||||
| Zero-load power in search mode |
2 / 2 / 3W |
2 / 2 / 3W |
3 / 3 /3W |
|||||||||
|
CHARGER |
||||||||||||
| AC Input |
Input voltage range: 187-265 VAC |
Input frequency: 45 – 65 Hz | ||||||||||
| Charge voltage ‘absorption’ |
14,4 / 28,8 / 57,6V |
|||||||||||
| Charge voltage ‘float’ |
13,8 / 27,6 / 55,2V |
|||||||||||
| Storage mode |
13,2 / 26,4 /52,8V |
|||||||||||
| Charge current house battery |
(4) |
20 / 10 / 6A |
35 / 16 / 9A |
50 / 25 / 13A |
||||||||
| Charge current starter battery |
1 A (12V and 24V models only) |
|||||||||||
| Battery temperature sensor |
Yes |
|||||||||||
|
GENERAL |
||||||||||||
| Programmable relay (5) |
Yes |
|||||||||||
| Protection (2) |
a – g |
|||||||||||
| Common Characteristics |
Operating temp. range: -40 to +65°C (fan assisted cooling) |
|||||||||||
|
Humidity (non-condensing): max 95% |
||||||||||||
|
ENCLOSURE |
||||||||||||
| Common Characteristics |
Material & Colour: Steel/ABS (blue RAL 5012) |
Protection category: IP 21 | ||||||||||
| Battery-connection |
16 / 10 / 10 mm² |
25 / 16 / 10 mm² |
35 / 25 / 10 mm² |
|||||||||
| 230V AC-connection |
G-ST18i connector |
|||||||||||
| Weight |
4,4 kg |
6,4 kg |
8,2kg |
|||||||||
| Dimensions (h x w x d) |
311 x 182 x 100 mm |
360 x 240 x 100 mm |
406 x 250 x 100 mm |
|||||||||
|
STANDARDS |
||||||||||||
| Safety |
EN-IEC 60335-1, EN-IEC 60335-2-29, EN 62109-1 |
|||||||||||
| Emission / Immunity |
EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3 |
|||||||||||
|
IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 |
||||||||||||
| Road vehicles |
ECE R10-4 |
|||||||||||
1) Can be adjusted to 60Hz and to 240V
2) Protection
a. Output short circuit
b. Overload
c. Battery voltage too high
d. Battery voltage too low
e. Temperature too high
f. 230VAC on inverter output
g. Input voltage ripple too high
